DIAL TI, FULL SET, STANDARD, .03 IN, .0005 IN GRAD, WHITE DIAL

.0005 In, .03 In, Dial Test Indicator, Full Set, 0-15-0, 3/8 In/.157 In Stems, .079 In/.039 In/.118 In Contact Points, Clamp and Hold Bar, 19.9mm Length, Anti-Magnet, Jeweled Bearing

• Preforms easy and accurate measurement of narrow or recessed areas, plus inside and outside diameters that dial indicators cannot access.
• Resistant to water and dust thanks to the one-piece bezel and crystal design with O-ring.
• The glare-free flat crystal face has a scratch-resistant coating.

• ACCURACY INCH+/-.0005 In
• CASE MATERIALPlastic Case
• CASE PART NUMBER21RAB973
• CATEGORY IDPrecision Measuring Tools
• MITUTOYO CATALOG PAGE NUMBERF-41
• CONTACT POINT DIAMETER INCH.039 In; .079 In; .118 In
• DIAL REAR0-15-0
• FACE COLORWhite
• GROUP IDTest Indicators
• INDIVIDUAL OR SETSet
• LENGTHMM19.9mm
• MECHANICAL OR DIGITALMechanical
• MEASURING FORCE>=.3N
• PRIMARY MEASURING RANGE LOWER INCH0 In
• PRIMARY MEASURING RANGE UPPER INCH.03 In
• PRODUCT MANUAL3049M Test Indicator
• PRIMARY (OD) CONTACT POINT MATERIALHardened Steel
• Product TypeDial Test Indicator
• RANGE0 - .03 In
• RESOLUTION OR GRADUATION INCH.0005 In
• SHIPPING HEIGHT INCH2
• SHIPPING LENGTH INCH5.5
• STEM DIAMETER.157 In; 3/8 In
• SHIPPING WEIGHT LBS1
• SHIPPING WIDTH INCH4
• THIRD DRILL DOWNInch
• US Harmonized Tariff Schedule9017.30.8000
